ASS 70 FD- INSULATED Folding Door Fold and Slide System
Technicial Specifications
- Max. wingspan
- 1500mm
- Max. wing height
- 3000mm
- Max. wing weight
- 150kg
- Max. view width
- 120mm
- Max. glass/panel thickness
- 45mm
- Frame Uf value (>=)
- 2.4W/(m²·K)
- Window Uw value (>=)
- 2.4W/(m²·K)
The thermally insulated Sliding Folding System Schüco ASS 70 FD (Folding Door) convinces with its narrow front widths and offers a wide range of types with excellent insulation for outdoor use.
Designed to meet aesthetic and functional requirements in Bodrum, this folding system offers numerous design possibilities for a barrier-free entrance with 90° corner puller opening variations, including a flat, thermally insulated floor threshold.
The elegantly designed magnetic lock and matching flat door handle offer an additional model option.
Flexible and quiet operating wing packages can optionally be folded to the right, left, inward or outward, providing a use suitable for Bodrum's special atmosphere.
